Gas Turbine Air Filter Paper

This filter media is applied to the air intake filter of gas turbine. It will filtrate the dust and impurities when air goes through media to enter in compression room.

Inquire Now Next Product

product details

This filter media is applied to the air intake filter of gas turbine. It will filtrate the dust and impurities when air goes through media to enter in compression room. Its filtration function keeps clean air to be supplied, which assures that gas turbine generator maintains safe and smooth operation. If the filtration precision is not high, the dirt will pass and stick on compressor blades, accordingly, washing times is increased to clear blades. Thus the generator set will consume more energy but output less electricity. Besides, the dust particles easily cause blockage at air intake and come into collision with compressor blades, which will seriously affect the performance and safety of generator set, shorten its lifetime. Therefore, high quality filter media is especially important to apply in the gas turbine air filters.

1. PRODUCT MODEL: FLA-9A-Y301C

Technical Data

Specification	Unit	Value
Grammage	g/㎡	115±5
Thickness	mm	0.35
Corrugation Depth	mm	0.42
Air Permeability	L/㎡·s	450±30
Max Pore Size	um	75±5
Mean Pore Size	um	60±5
Burst Strength	Kpa	250
Longitudinal Stiffness	mN.m	3.0
Moisture	%
Color		Light Yellow

2. PRODUCT MODEL: FLA-9A-W301C

Technical Data

Specification	Unit	Value
Grammage	g/㎡	135±5
Thickness	mm	0.45
Corrugation Depth	mm	0.45
Air Permeability	L/㎡·s	300±30
Max Pore Size	um	60±5
Mean Pore Size	um	50±5
Burst Strength	Kpa	320
Longitudinal Stiffness	mN.m	5.0
Moisture	%	22±2
Color		White

3. PRODUCT MODEL: FLA-9A-Y201P

Technical Data

Specification	Unit	Value
Grammage	g/㎡	140±5
Thickness	mm	0.45
Corrugation Depth	mm	0
Air Permeability	L/㎡·s	200±30
Max Pore Size	um	55±5
Mean Pore Size	um	50±5
Burst Strength	Kpa	430
Longitudinal Stiffness	mN.m	4.5
Moisture	%	22±2
Color		Yellow
