Oil Filter Paper

Oil filter paper is used in oil filter elements, which protect the lubrication system of the engine. It will filtrate the impurities when the oil goes through media to enter in the system. Therefore, its filtration function keeps clean oil to be supplied, prevents the oil system blocked and protects engine from damage and abrasion.

Inquire Now Next Product

product details

1. PRODUCT MODEL: FLA-9A-Y301C

Technical Data

Specification	Unit	Value
Grammage	g/㎡	115±5
Thickness	mm	0.35
Corrugation Depth	mm	0.42
Air Permeability	L/㎡·s	450±30
Max Pore Size	um	75±5
Mean Pore Size	um	60±5
Burst Strength	Kpa	250
Longitudinal Stiffness	mN.m	3.0
Moisture	%
Color		Light Yellow

2. PRODUCT MODEL: FLA-9A-W301C

Technical Data

Specification	Unit	Value
Grammage	g/㎡	135±5
Thickness	mm	0.45
Corrugation Depth	mm	0.45
Air Permeability	L/㎡·s	300±30
Max Pore Size	um	60±5
Mean Pore Size	um	50±5
Burst Strength	Kpa	320
Longitudinal Stiffness	mN.m	5.0
Moisture	%	22±2
Color		White

3. PRODUCT MODEL: FLA-9A-Y201P

Technical Data

Specification	Unit	Value
Grammage	g/㎡	140±5
Thickness	mm	0.45
Corrugation Depth	mm	0
Air Permeability	L/㎡·s	200±30
Max Pore Size	um	55±5
Mean Pore Size	um	50±5
Burst Strength	Kpa	430
Longitudinal Stiffness	mN.m	4.5
Moisture	%	22±2
Color		Yellow
